Product Details:
|
| Frequency: | 20Khz | Power: | 1500w |
|---|---|---|---|
| Horn Material: | Titanium | Horn Size: | Customized |
| Generator: | Digital | Type: | Diamond,Cone Shape |
| Weight: | 15kg | ||
| High Light: | 20Khz Ultrasonic Dispersion Equipment,Nano Ultrasonic Dispersion Equipment,Nano Dispersion Ultrasound Devices |
||
High Power Stable 20Khz Ultrasonic Nano Dispersion Equipment
Parameter
| Model | SONO20-1000 | SONO20-2000 | SONO15-3000 | SONO20-3000 |
| Frequency | 20±0.5 KHz | 20±0.5 KHz | 15±0.5 KHz | 20±0.5 KHz |
| Power | 1000 W | 2000 W | 3000 W | 3000 W |
| Voltage | 220/110V | 220/110V | 220/110V | 220/110V |
| Temperature | 300 ℃ | 300 ℃ | 300 ℃ | 300 ℃ |
| Pressure | 35 MPa | 35 MPa | 35 MPa | 35 MPa |
| Intensity of sound | 20 W/cm² | 40 W/cm² | 60 W/cm² | 60 W/cm² |
| Max Capacity | 10 L/Min | 15 L/Min | 20 L/Min | 20 L/Min |
| Tip Head Material | Titanium Alloy | Titanium Alloy | Titanium Alloy | Titanium Alloy |
Description
Product introduction of industrial-grade 1500W ultrasonic crushing and mixing equipment: 1. Ultrasonic dispersion applications can be applied to most chemical reactions, such as extraction (extraction) and separation, synthesis and degradation, biodiesel production, sewage treatment, cell crushing, and dispersion And agglomeration, extraction of bio-nano, etc.; 2. Ultrasonic dispersion principle, when the ultrasonic vibration is transmitted to the liquid, due to the high sound intensity, it will excite a strong cavitation effect in the liquid, thereby generating a lot of voids in the liquid Foaming.
Ultrasonic dispersion equipment is suitable for various solutions, including high-viscosity solutions. The normal power is 1.0KW to 3.0kw. The particles can be dispersed to nanometer level.
Industrial applications usually mix different liquids or solids with liquids to formulate various products. Such as: liquid beverages/pharmaceuticals, paints, coatings, detergents, etc. In order to better mix various substances into the solution, it is necessary to disperse the initially agglomerated substances into a dispersion. Ultrasonic cavitation immediately creates countless areas of high pressure and low pressure in the solution. These high-pressure and low-pressure areas continuously collide with each other to generate strong shearing force and deagglomerate the material.
1. The dispersion efficiency is high, and the efficiency can be increased by more than 200 times in the appropriate field.
2. The dispersed particles are finer, with better uniformity and stability.
3. A snap flange is usually installed for easy movement and cleaning.
Ultrasonic dispersion equipment application, can be applied to most chemical reactions, such as extraction (extraction) and separation, synthesis and degradation, biodiesel production, sewage treatment, cell crushing, dispersion and agglomeration, extraction of bio-nano, etc.; principle of ultrasonic dispersion equipment When the ultrasonic vibration is transmitted to the liquid, due to the high sound intensity, a strong cavitation effect will be excited in the liquid, thereby generating a large number of cavitation bubbles in the liquid. As these cavitation bubbles are generated and blasted, micro-jets will be generated to break up the solid particles that are heavy in the liquid.
Performance characteristics
1. Strong equipment stability and high energy conversion rate
2. Focused wave and low energy consumption
3. Simple operation and intelligent control
