High Power Ultrasonic Homogenizer Sonicator 20khz Food Mixing

High Power Ultrasonic Homogenizer Sonicator 20khz Food Mixing

ultrasonic homogenizer sonicator

ultrasonic cell disruptor

Place of Origin:


Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
Digital Generator
Titanium Alloy
20 L/Min
Payment & Shipping Terms
Minimum Order Quantity
Packaging Details
Delivery Time
Payment Terms
T/T, Western Union
Supply Ability
Product Description

high power ultrasonic homogenizer sonicator 20khz food mixing equipment



Model SONO20-1000 SONO20-2000 SONO15-3000 SONO20-3000
Frequency 20±0.5 KHz 20±0.5 KHz 15±0.5 KHz 20±0.5 KHz
Power 1000 W 2000 W 3000 W 3000 W
Voltage 220/110V 220/110V 220/110V 220/110V
Temperature 300 ℃ 300 ℃ 300 ℃ 300 ℃
Pressure 35 MPa 35 MPa 35 MPa 35 MPa
Intensity of sound 20 W/cm² 40 W/cm² 60 W/cm² 60 W/cm²
Max Capacity 10 L/Min 15 L/Min 20 L/Min 20 L/Min
Tip Head Material Titanium Alloy Titanium Alloy Titanium Alloy Titanium Alloy



Ultrasound homogenization technology is mainly used in dairy products.
In natural state, the diameter of the fat globules is uneven, ranging from 1 to 10 μm, generally 2 to 5 μm [1]. These fat globules float on the surface of the milk to form a creamy layer due to the buoyancy, so that milk is produced. Delamination. The presence of these fat globules greatly affects the appearance and taste of milk and dairy products. If the milk is homogenized, the diameter of the fat globules can be controlled at about 2 μm. At this time, the surface area of ​​milk fat increases and the buoyancy decreases, thereby avoiding stratification and achieving a uniform effect. The unique effect of homogenization improves the quality of the product from the aspects of appearance and taste. Therefore, homogenization is a very important part of the pretreatment process of milk products.
After the raw milk is homogenized, the appearance, taste, and nutritional quality of the dairy product will be greatly improved, so homogenization is an extremely important part of the pretreatment process of dairy products. Due to cavitation and other physical effects, ultrasonic waves have a homogeneous effect on materials. Many studies have reported the homogeneous effect of ultrasound on cow milk. Ultrasonicate 0.5 kg of milk using an ultrasonic cell pulverizer. The results showed that the homogenization effect of ultrasonic homogenization at 40 ℃ for 10 min was the best. The homogenizing effect of ultrasound on milk. At a frequency of 40 k Hz and a power density of 0.8 W / cm2, the homogenization of ultrasound was performed for 1 min. The average particle size of fat globules was 0.584 µm, and the particle size of 94% of fat globules was less than 1 µm. Schmidt studied the homogenizing effect of ultrasound on milk. Under laboratory conditions of 60 ℃ and 20 ± 1 k Hz, 4 ml of low-fat milk was homogenized, and the average fat particle size after processing was less than 1 µm. The effect of high-intensity ultrasound on milk fat was studied. After sonication, the fat globule size decreased by 81.5%. Homogeneous effect of raw milk fat globules. The study found that compared with traditional homogenization, high-amplitude ultrasound has better homogenization effect on milk. Under 450 W ultrasound for 10 min, the diameter of the fat globules was 0.725 µm; at 180 W, 10 min was similar to the traditional homogenization effect. Studies show that compared with traditional methods, ultrasound has a better homogenization effect on milk, and the homogenization effect increases with the increase of homogenization time and ultrasonic power. The combination of ultrasonic and heating can achieve the dual effects of homogenization and pasteurization. Human milk was homogenized by ultrasound and tested for the effects of Ig A and Ig G antibodies, lactoferrin, and bacterial content in human milk. The results showed that low temperature ultrasonic homogenized milk can reduce fat loss without destroying globulins Ig A, Ig G and lactoferrin.


Ultrasonic homogenizer also applied in:

• Cell disrupter (extraction of plant substances, disinfecting, enzyme deactivation)

• Therapeutic ultrasound, i.e. induction of thermolysis in tissues (cancer treatment)

• Decrease of reaction time and/or increase of yield

• Use of less forcing conditions e.g. lower reaction temperature

• Possible switching of reaction pathway

• Use of less or avoidance of phase transfer catalysts

• Degassing forces reactions with gaseous products

• Use of crude or technical reagents

• Activation of metals and solids

• Reduction of any induction period

• Enhancement of the reactivity of reagents or catalysts

• Generation of useful reactive species
