High Speed Ultrasonic Cutting Tool Strong Tensile Strength No Wire Loss

High Speed Ultrasonic Cutting Tool Strong Tensile Strength No Wire Loss

ultrasonic cutting tool

ultrasonic slitting machine

Place of Origin:

China

Brand Name:

Rps-sonic

Certification:

CE

Model Number:

RPS-C40

Contact Us

Request A Quote
Product Details
Frequency:
40khz
Blade Material:
Titumium
Cutting Thickness:
1~7mm
Applcation:
Fabric Cutting
Power:
500W
Operate Type:
By Hand Or Robot
Payment & Shipping Terms
Minimum Order Quantity
1pcs
Price
Negotiable
Packaging Details
CARTON
Delivery Time
5~8days
Payment Terms
T/T, Western Union
Supply Ability
200PCS/MONTH
Product Description

40Khz hand held ultrasonic cutting machine fabric towel cutting and trimming



Introduction

Ultrasonic cutting machine uses ultrasonic energy for cutting processing. There is no need for a traditional cutting edge. Traditional cutting uses a knife with a sharp edge to press the material to be cut. This pressure is concentrated at the cutting edge, and the pressure is very large, exceeding the shear strength of the material being cut, and the molecular binding of the material is pulled apart and cut off. Because the material is pulled apart by strong pressure, the cutting edge of the cutting tool should be very sharp, and the material itself must withstand relatively large pressure. It is not good for cutting soft and elastic materials, and it is more difficult for viscous materials.
Ultrasonic cutting also has a great advantage, that is, it can melt the cutting material while cutting. The cutting area is perfectly sealed to prevent loosening of the tissue of the material being cut (such as flashing of textile materials).So ultrasonic cutting is widly used in fabric, textile,
 Home textil
es ,Non-woven,seat cushion, sound insulation cotton.





Parameter



Machine Ultrasonic cutting
Frequency(KHz) 40Khz
Power 500 W
Cutting Blade / Horn Titanium
Voltage(V) 220V
Cutting thickness 1~7mm
Horn amplitude 30μm
Equipment weight 6KG



Advantages

1. Fast, economical, high sewing strength and strong tensile strength
2. Independent cutting and sewing, with soft melting and trimming effect, no wire loss, no damage, no burrs.
3. No need for auxiliary materials (such as staples, glue, paper clips, etc.). )
4. No time-consuming warm-up and recovery required
5, no pollution, no use of toxic adhesives and solvents, environmental protection and health
6. There is no needle eye on the sewing edge, which can prevent the penetration of chemicals, pathogens and small harmful particles, which is safe and hygienic.



Application:

Textile materials suitable for ultrasonic cutting processing: 100% synthetic fibers such as nylon, polyester, polypropylene, certain polyethylenes, modified acrylic resins, certain vinyl compounds, polyurethane compounds, films, Coated paper, etc. It also includes synthetic fibers mixed with 35-50% non-synthetic fiber components.

The ultrasonic heat sealing or cutting process can be used to form continuous work applications, similar to the traditional sewing machine working mode, such as the production of protective clothing, shutters, etc. Welding stand-alone "sewing" equipment or standard ultrasonic welding machines can accomplish this process.
