High Power Ultrasonic Welding Tool 15khz 5000W High Precision

High Power Ultrasonic Welding Tool 15khz 5000W High Precision

diy ultrasonic welder

continuous ultrasonic welding

Place of Origin:

China

Brand Name:

Rps-sonic

Certification:

CE

Model Number:

rps-w15-S329

Contact Us

Request A Quote
Product Details
Name:
Ultrasonic Welder
Frequency:
15Khz
Power:
5000W
The Height Of The Frame In Max:
280mm
Payment & Shipping Terms
Minimum Order Quantity
1pcs
Price
Negotiable
Packaging Details
WOOD BOX
Delivery Time
5-8days
Payment Terms
T/T, Western Union
Supply Ability
200PCS/MONTH
Product Description

15khz high power ultrasonic welding machine 5000W Automatic high precision

A.The principle of ultrasonic welding

The ultrasonic generator generates the signal frequency required by the ultrasonic transducer, and then uses the thermoplasticity of the plastic to generate heat at a very high speed between the molecules by using high-frequency friction between the working surfaces. When the heat is sufficient to melt, the ultrasonic wave is stopped. Vibration, at this time the workpiece joint is solidified by melting, complete the processing procedure! The traditional ultrasonic generator is manually frequency-modulated, and HZ-2000 digital ultrasonic generator realizes automatic frequency tracking, real-time power display, and friendly communication of human-machine interface!



B.Function

1. Frequency auto-chasing: intelligent control system, frequency auto tracking.

2. amplitude adjust Infinitely : amplitude adjust Infinitely , amplitude increase and decrease by 5%;

3. intelligent protection: frequency offset protection, output overloading protection, mold damage protection;

4. electrical components: all pneumatic components and main electronic components of the machine are imported from Germany and Japan;

5. fuselage structure: the frame of the machine adopt special steel structure and made by precision cast aluminum CNC machining processing , the frame is more precise and more stable

C.Parameter:

Frequency 15Khz 30KHz
Generator 3000W/5000W 2000W
Welding model Time model energy model, power model, depth model
Distance micro-adjustment 20-100mm Precision:0.01 mm
The height of the frame in max 280mm
Input Voltage 220V/110V





Advantages of Ultrasonic welding
There are many advantages to using ultrasonic welding.

It is a fast, clean, efficient, and repeatable process that produces strong, integral bonds while consuming very little energy. No solvents, adhesives, mechanical fasteners or external heat are required. Finished welding-material are strong and clean. Difficult materials can be welded ultrasonically. Part welding are cycled quickly because the energy transferred to the joint and released as heat occurs very rapidly and is confined to the immediate joint area. The rapid dissipation of heat makes this process considerably faster than other methods of welding.

An ultrasonic welding system’s tooling and/or application can be quickly changed offering flexibility and versatility not found in many other welding processes. In addition, the relatively low-cost investment in ultrasonic equipment vs. its high reliability, long life, and consistent, repeatable performance, makes ultrasonic welding the preferred method of welding. Ultrasonic welding is widely accepted and is used in the automotive, medical, electrical and electronic, communications, appliance, consumer products, toys, textile and packaging industries. It is an economical process that can significantly increase production and lower welding costs.

Ultrasonic Welders can be easily integrated in automation manufacturing environment and 100 % all electric control of the latest equipment provides unprecedented repeatability, reliability and accuracy to the process.

High Power Ultrasonic Welding Tool 15khz  5000W High Precision 0
