30Khz 500w Robot Arm Ultrasonic Cutting System Auto Tracking Type With RS485

30Khz 500w Robot Arm Ultrasonic Cutting System Auto Tracking Type With RS485

Auto Tracking Type Ultrasonic Cutting System

30Khz Ultrasonic Cutting System

500w Ultrasonic Cutting Device

Place of Origin:

China

Brand Name:

Rps-sonic

Certification:

CE

Model Number:

RPS-C30

Contact Us

Request A Quote
Product Details
Frequency:
30Khz
Power:
500w
Material:
Titanium
Blade Width:
1mm
Weight:
6kg
Generator:
Digital,can Conect PLC
Power Supply:
220V
Payment & Shipping Terms
Minimum Order Quantity
1pcs
Price
negotiable
Packaging Details
CARTON
Delivery Time
1DAYS
Payment Terms
T/T
Supply Ability
200PCS/MONTH
Product Description

30Khz 500w Robot Arm Ultrasonic Cutting System For Fabric Cashmere Cutting With RS485

30Khz Robot arm Ultrasonic cutting system for fabric Cashmere cutting



Parameter



Frequency 30Khz
Frequency adjustment Auto-tracking type
Max. power output 500W
Power output Infinitive adjustment
Power supply AC200V 50/60Hz
Outer dimension (mm) 120*120*380
Weight 6kg
Blade thickness 1mm



Different fabric cutting processes



The cutting process of fabrics is generally divided into two types: cold cutting and hot cutting. Both of these cutting methods have certain limitations.

Ultrasonic fabric cutting is compared with cold cutting. When using ultrasonic fabric cutting, after the thermoplastic material is cut, the edges of the cut will be fused; compared with thermal cutting, using ultrasonic cutting can make the edges of the cut fabric very soft , To avoid excessive thickening of edges due to melt shrinkage. Since the ultrasonic is heated from the inside of the fabric, there will be no yellowing of the fabric.



Description



The basic structure of the sonic cutting machine. Ultrasonic transducer, ultrasonic horn, ultrasonic cutting knife, ultrasonic generator.
Ultrasonic generator
The mains electricity is converted into high frequency and high voltage alternating current, which is output to the ultrasonic transducer. Ultrasonic transducer is equivalent to energy conversion device, it can convert the input electric energy into mechanical energy, namely ultrasonic wave. The ultrasonic transducer stretches back and forth in the longitudinal direction, and the frequency of the stretch movement is equal to the frequency of the high-frequency alternating current supplied by the driving power source.
Ultrasonic horn
The ultrasonic horn amplifies the output amplitude of the ultrasonic transducer.
Ultrasonic cutter
Amplify the amplitude further and focus the ultrasound.
Ultrasonic waves are output, and the cutting knife is used to concentrate the ultrasonic energy into the cutting part of the material to be cut. Under the action of huge ultrasonic energy, this part instantly softens and melts, and its strength is greatly reduced. Only a small amount of force is required to achieve the purpose of cutting materials.



Ultrasonic cutting machine features, does not need sharp blades, does not require a lot of pressure, and will not chip or damage the cutting material.
1. The cutting knife is doing ultrasonic vibration, the friction resistance is very small, and the material to be cut is not easy to stick to the blade. It has obvious cutting effect on frozen, viscous and elastic materials. It is especially effective for cutting food, rubber or objects that are inconvenient to apply pressure.
2. At the same time of cutting, the cutting part has fusion. Sealing the cutting part can prevent the loosening of the cut material (such as the flash of textile materials). The use of the ultrasonic cutting machine can also be expanded, such as digging holes, shoveling, scraping paint, carving, slitting and so on.

This equipment uses the high-speed micro-vibration of 20,000 to 30,000 times per second of the blade to reduce the friction between materials and the difficult-to-cut synthetic resin products, rubber products, non-woven fabrics, film, composite products and other industrial collars. Damage caused by the city’s products,

It can be used for manual work or installed on automated equipment.



30Khz 500w Robot Arm Ultrasonic Cutting System Auto Tracking Type With RS485 0
