Ultrasonic slitting of fabric rolls for polyster and non-woven fabric

Ultrasonic slitting of fabric rolls for polyster and non-woven fabric

Place of Origin:

China

Brand Name:

RPS-SONIC

Certification:

CE

Model Number:

SONO-35-500

Contact Us

Request A Quote
Product Details
Blade Amplitude:
10-60μm
Blade Size:
Customized
Cutting Blade:
Alloy Steel
Cutting Speed:
0-100 Mm/s
Generator:
Digital,can Conect PLC
Handle Length:
150 Mm
Height:
4kg
Horn Width:
2~4mm
Package:
Carton
Power Output:
Infinitive Adjustment
Type:
Handheld
Usage:
For Farbic Cutting And Sealing
Useage:
Nonwoven Welding ,cutting
Weight:
1.5 Kg
Welding Type:
Continues Welding
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
negotiable
Packaging Details
Carton or wooden box
Delivery Time
3-5days
Payment Terms
T/T, D/A, D/P
Supply Ability
40sets per week
Product Description

Ultrasonic slitting of fabric rolls for polyster and non-woven fabric



Ultrasonic fabric slitting is a method of cutting fabrics using high-frequency ultrasonic vibrations. It is a non-contact cutting technique that uses ultrasonic energy to create clean and precise cuts in various types of fabrics. The process involves the use of an ultrasonic cutting blade or horn, which vibrates at a frequency higher than the upper limit of human hearing (typically between 20 kHz and 40 kHz).

The ultrasonic energy generated by the vibrating blade causes the fabric to be locally heated and softened, allowing the blade to penetrate and cut through the material. The high-frequency vibrations create rapid oscillations that create a shearing effect, resulting in a clean cut without fraying or unraveling of the fabric edges.

Ultrasonic fabric slitting offers several advantages over traditional cutting methods. It is a fast and efficient process that can be automated, improving production speed and reducing labor costs. It produces precise and consistent cuts, even in complex shapes or patterns, without the need for additional finishing processes. Additionally, the non-contact nature of the cutting reduces the risk of damage to delicate or sensitive fabrics.

This technology is commonly used in various applications, including apparel manufacturing, automotive upholstery, medical textiles, and technical textiles. It is particularly useful for cutting synthetic fabrics, such as nylon, polyester, and acrylic, as well as materials that are prone to fraying or unraveling.

Can ultrasonic fabric slitting be used on natural fabrics like cotton or silk?

Yes, ultrasonic fabric slitting can be used on natural fabrics like cotton or silk. While synthetic fabrics are often more commonly associated with ultrasonic cutting due to their tendency to fray and unravel, the technology is also suitable for cutting natural fabrics.

When using ultrasonic fabric slitting on natural fabrics, it's important to consider the characteristics of the specific fabric being cut. Natural fabrics like cotton or silk may have different properties compared to synthetic fabrics, such as lower melting points or greater sensitivity to heat. Thus, adjustments may be required in terms of the ultrasonic power, cutting speed, or blade design to ensure optimal cutting results without damaging the fabric.

In some cases, additional measures might be necessary to control the heat generated during cutting, such as cooling systems or using lower power settings. It's always recommended to conduct proper testing and experimentation to determine the ideal cutting parameters for specific natural fabrics to achieve the desired results.

Ultrasonic fabric slitting has been successfully applied to a wide range of natural fabrics, including cotton, silk, linen, wool, and others. However, it's important to note that the suitability of the technique may vary depending on the specific fabric and its characteristics, so it's advisable to consult with equipment manufacturers or experts in ultrasonic cutting to ensure proper implementation.

Ultrasonic slitting of fabric rolls for polyster and non-woven fabric 0

What is the parameter of the ultrasonic fabric cutting?

Frequency 35Khz
Frequency adjustment Auto-tracking type
Max. power output 500W
Power output Infinitive adjustment
Power supply AC110V or 200V 50/60Hz
Outer dimension (mm) 120*120*380
Weight 5kg
Horn width 0.5mm
Material of cutting head titanium

What is the advantage of ultrasonic slitting machine?

Ultrasonic fabric slitting offers several advantages over traditional fabric cutting methods. Some of the key advantages include:

Clean and Precise Cuts: Ultrasonic fabric slitting produces clean and precise cuts without fraying or unraveling of the fabric edges. The high-frequency vibrations create a shearing effect, resulting in a sharp and well-defined cut, even in intricate shapes or patterns.

Non-Contact Cutting: Ultrasonic cutting is a non-contact process, which means that the fabric being cut is not subjected to direct mechanical pressure. This reduces the risk of fabric distortion, stretching, or damage, especially for delicate or sensitive materials.

Versatility: Ultrasonic fabric slitting can be used on a wide range of fabric types, including synthetic fabrics like nylon, polyester, and acrylic, as well as natural fabrics like cotton, silk, and wool. It is suitable for cutting both thin and thick fabrics, making it versatile across various applications.

Automation and Speed: Ultrasonic cutting can be easily integrated into automated production lines, improving production speed and efficiency. It eliminates the need for manual cutting, resulting in increased productivity and reduced labor costs.

No Additional Finishing Required: The clean and precise cuts produced by ultrasonic fabric slitting often eliminate the need for additional finishing steps, such as hemming or sealing the fabric edges. This can save time and reduce production steps, leading to cost savings.

Reduced Material Waste: Ultrasonic cutting minimizes material waste since it creates narrow and accurate cuts. The precise cutting helps optimize fabric usage and reduces scrap or excess material.

Enhanced Safety: Ultrasonic fabric slitting is generally considered safer than traditional cutting methods. The non-contact nature of the process reduces the risk of injuries associated with handling sharp blades or rotary cutters.

Overall, ultrasonic fabric slitting offers improved cutting precision, efficiency, and versatility compared to traditional cutting methods. It is particularly beneficial for applications that require clean and accurate cuts in various types of fabrics.

Ultrasonic slitting of fabric rolls for polyster and non-woven fabric 1

Video for your reference:
