40khz 500w Hand Push Ultrasonic Fabric Cutting and Sealing Machine

40khz 500w Hand Push Ultrasonic Fabric Cutting and Sealing Machine

500w ultrasonic fabric cutting machine

40khz ultrasonic fabric cutting machine

0.5mm ultrasonic fabric cutter

Place of Origin:

China

Brand Name:

Rps-sonic

Certification:

CE

Model Number:

C40-T

Contact Us

Request A Quote
Product Details
Frequency:
40khz
Power:
500w
Width:
0.5mm
Horn Material:
Steel
Application:
Used For Fabric Cutting And Sealing
Voltage:
110V Or 220V,50hz
Generator Type:
Digital Generator
Maxi Fabric Thickness:
1cm
Cutting Method:
Customized
Payment & Shipping Terms
Minimum Order Quantity
1pcs
Price
negotiable
Packaging Details
CARTON
Delivery Time
1DAYS
Payment Terms
T/T
Supply Ability
200PCS/MONTH
Product Description

40khz 500w Hand Push Ultrasonic Fabric Cutting and Sealing Machine

40khz 500w Hand Push Ultrasonic Fabric Cutting and Sealing Machine 0

An ultrasonic curtain fabric cutter is a specialized device that utilizes ultrasonic technology to cut curtain fabrics with precision and efficiency. The cutter consists of several essential components:

  1. Ultrasonic Generator: The generator converts the electrical energy into high-frequency sound waves, typically in the range of 20 kHz to 40 kHz.

  2. Transducer: The transducer is responsible for converting the electrical signals from the generator into mechanical vibrations.

  3. Horn or Blade: The horn, also known as the cutting blade, is attached to the transducer. It amplifies the mechanical vibrations and focuses them on a small area.

  4. Anvil: The anvil is a support structure or surface against which the fabric is placed during cutting.

  5. Cutting Mechanism: The cutting mechanism is responsible for moving the fabric across the cutting area.

40khz 500w Hand Push Ultrasonic Fabric Cutting and Sealing Machine 1











Frequency 40Khz
Frequency adjustment Auto-tracking type
Max. power output 500W
Power output Infinitive adjustment
Power supply AC110V or 200V 50/60Hz
Outer dimension (mm) 120*120*380
Weight 5kg
Horn width 0.5mm
Material of cutting head  titanium

40khz 500w Hand Push Ultrasonic Fabric Cutting and Sealing Machine 2







Ultrasonic fabric cutters are widely used in various industries for cutting fabrics and other materials. Here are some applications of ultrasonic fabric cutters:

  1. Textile Industry: Ultrasonic fabric cutters are extensively used in the textile industry for cutting fabrics, including woven, non-woven, and knitted fabrics. They can precisely cut fabrics without fraying or unraveling the edges, resulting in clean and sealed cuts. This technology is particularly useful for cutting delicate fabrics like silk, chiffon, and lace.

  2. Apparel Manufacturing: In garment manufacturing, ultrasonic fabric cutters are used for cutting various components of garments such as collars, cuffs, pockets, and sleeves. The clean and sealed cuts provided by ultrasonic cutting ensure high-quality finished products.

  3. Automotive Industry: Ultrasonic fabric cutters find applications in the automotive industry for cutting fabrics used in car interiors, including seat covers, headliners, and carpeting. The precise cutting capability of ultrasonic cutters helps in achieving accurate and consistent cuts, ensuring a perfect fit during the assembly process.

  4. Technical Textiles: Technical textiles, which are used for specialized applications like filtration, geotextiles, medical textiles, and protective clothing, often require precise cutting. Ultrasonic fabric cutters are suitable for cutting technical textiles due to their ability to cut complex shapes and seal the edges, ensuring functionality and durability.

  5. Home Furnishings: Ultrasonic fabric cutters are used in the production of home furnishing items such as curtains, upholstery, bedding, and pillows. The clean and sealed cuts provided by ultrasonic cutting help prevent fraying and maintain the overall appearance and quality of the products.

  6. Packaging Industry: Ultrasonic fabric cutters find applications in the packaging industry for cutting various packaging materials, including polypropylene, polyethylene, and laminated films. They can create customized shapes and sizes with precise and sealed edges, ensuring efficient packaging solutions.

40khz 500w Hand Push Ultrasonic Fabric Cutting and Sealing Machine 3

BENEFITS OF ULTRASONIC CURTAIN FABRIC CUTTING:

  1. Precision: Ultrasonic cutting provides a high level of precision, allowing for clean and accurate cuts. The technology uses focused sound waves to create a localized melting effect on the fabric, resulting in a precise cut without fraying or unraveling.

  2. Sealing: One of the notable benefits of ultrasonic cutting is that it simultaneously seals the edges of the fabric while cutting. As the ultrasonic energy melts the fabric, it creates a sealed edge that prevents fraying and eliminates the need for additional finishing processes.

  3. Efficiency: Ultrasonic cutting is a fast and efficient process. It operates at high speeds, enabling rapid cutting of curtain fabrics. The non-contact nature of ultrasonic cutting also reduces the risk of fabric distortion or damage.

  4. Versatility: Ultrasonic cutting can be used with a wide variety of curtain fabrics, including natural fibers (such as cotton and silk) as well as synthetic fabrics (such as polyester and nylon). It is particularly useful for cutting fabrics that are difficult to cut with traditional methods or those prone to fraying.

  5. Automation: Ultrasonic cutting can be easily integrated into automated production lines. It can be programmed to cut fabrics into specific shapes and sizes, making it suitable for mass production environments.

40khz 500w Hand Push Ultrasonic Fabric Cutting and Sealing Machine 4

40khz 500w Hand Push Ultrasonic Fabric Cutting and Sealing Machine 5 40khz 500w Hand Push Ultrasonic Fabric Cutting and Sealing Machine 6



Related Ultrasonic Cutters

40khz 500w Hand Push Ultrasonic Fabric Cutting and Sealing Machine 7 40khz 500w Hand Push Ultrasonic Fabric Cutting and Sealing Machine 8
  •

FAQ

1. Are you a manufacturer or trader?

A:Yes, we are manufacturer. Welcome to visit us.

2. What is the MOQ of ultrasonic machine ?

A: 1 set is accept.

3. Can I get a lower price if I order large quantities?

A: Yes, cheaper prices with more bigger size orders.

4. Could you advise to us the design based on our special requirements or based on our object samples?

A: Of course, we can do. Please tell us your idea or your application. If you have sample object,send it to us or send detail pictures.

5. Could we as your agent?

A: Of course.We are looking for sole agent in Country who have the willing to cooperate with us for long business term.

6. When will you send out the ultrasonic machine after receiving the order?

A: Based on the order quantity, the goods will be send out within 2 -7days.

7. How about the quality guarantee period of ultrasonic machine ?

A: One year! Except for the horn.

8. How can you guarantee the production quality?

A: We have more than 10 years production experience and we have strictly quality control system in our production process. 4 times inspection for each ultrasonic machinebefore the delivery, Third part inspection acceptable.

9. How soon we can get email response from your team?

A: Less than 6 hours

10. What's the list of certificates you holds?

A: CE certificate
