Place of Origin:
China
Brand Name:
Rps-sonic
Certification:
CE
Model Number:
RPS-AC20
Contact Us
20Khz 5000w Fully Automatic Ultrasonic Food Cutting Machine For Braed/Cake/Cheese Cutting
20Khz Automatic Ultrasonic cutting machine for braed/cake/cheese cutting
Parameter
| Automatic Ultrasonic Cutting Machine | |
| Dimensions (length) x (width) x (high) | 800*850*1760mm (L x W x H) |
| Weight | 300Kg |
| Rated power | 3kw |
| Cutting speed | 60 knives / min |
| Maximum cut size | Round: up to 12 inches each cake; |
| Rectangle: up to 600 x 450 mm | |
| Maximum products depth | 120mm |
| Number of cutting knives | 3 |
| Cutting knife size | 255mm |
| Whether it can be rotated | Cutting plateform rotated |
| Cut type | Round, sliced, rectangular |
| Conveyor belt (several) | No |
| Rack structure | Stainless steel |
| Safety protection system | Safety protection grating |
| Screen | 7 inch touch screen |
| Control cabinet | Built-in |
| Control System | Multi-axis Control System |
| Cutting knife control system | Servo motor |
| Electric supply | Single phase, 220v, 50-60Hz |
| Compressed air connection | 0.4Mpa |
| Product into and out of material | Manually |
| Machine mobility | Pully |
| Can be controlled by touch screen | Yes |
Description
The ultrasonic cutting machine can cut all kinds of round or rectangular products. The machine has a unique product support and a fully automatic product positioning system. It can cut all kinds of frozen or normal temperature round and rectangular products. The device is also equipped with a light curtain safety sensor, which reduces cycle time by eliminating opening and closing doors. This machine is suitable for manufacturers who produce 50-100 kinds of products per hour.
Ultrasonic food cutting knife can effectively reduce food debris when cutting. It is suitable for pastry foods of different thickness and hardness, and is suitable for families or factories with small production volumes.
Ultrasonic food cutting knives because the cutting knives are doing ultrasonic vibration, the friction resistance is very small, and the material to be cut is not easy to stick to the blade. This is especially effective for cutting sticky and elastic materials, frozen materials, such as cakes, pizza, chocolate, etc., or objects that are inconvenient to apply pressure.
Ultrasonic food cutting equipment uses high-frequency ultrasonic vibrations and cuts with a sharp blade, which can reduce the pressure on the food and extend the service life of the knife. FUNSONIC provides complete customization of OEM components, kits and knife angles. Typical applications include cheese cutting, cake and dessert product cutting, confectionery product cutting, meat cutting, sandwich and packaging cutting.
Dairy manufacturers often use ultrasonic food cutting systems to dispense hard or mildly seasoned cheeses that are difficult to slice.
According to the customer's specific requirements, the length and height of the ultrasonic blades may be different. They are made of titanium alloy or stainless steel.
The digital generator of the ultrasonic food cutting equipment provides the function of increasing, decreasing and modifying its working parameters, and can adjust the amplitude, output power and time and other parameters.
For ultrasonic food cutting applications embedded in automated production lines, we provide vibration groups with different frequencies from 20, 30 to 40 kHz according to the requirements of end users to keep work safe and noise-free during the manufacturing stage.
Features
-Brand new self-developed high-efficiency ultrasonic generator drive technology, stable and reliable work.
-It can effectively improve the work efficiency of the operators and reduce the work intensity.
-The cut food has a neat surface, no debris, and beautiful appearance. .
-Titanium alloy cutting knife, food grade material, users can use it safely
- Small footprint
-Equipped with EDG generation system, stable power output
